WIDIA Erickson BTKV40BEM06050MBTKV40 Shank Toolholder, End Mill Adapter, 6 mm Cutting Tool Shank Diameter, 50 mm Length
Product details
| Management number | 221398498 | Release Date | 2026/05/03 | List Price | US$151.73 | Model Number | 221398498 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Erickson taper face bt contact taper tooling is manufactured from premium materials and to the latest jis b 6339 specification standard with an At3 7/24 taper per is0-1974. Controlled, increased flange thickness to the rear of the flange gains face contact between spindle and holder. The Btkv40 tools are prebalanced to a high specification that will perform effectively up to 20,000 rpm. For any applications higher than 20,000 rpm, widia recommends that the complete toolholder assembly (toolholder, retention knobs, collets, hardware, and cutting tools) be balanced as one identity.
- End mill adapters used to grip straight shank end mills and used in milling applications
- Do not overtighten lock screw, refer to torque specification as listed in widia catalog
- High axial repeatability due to face contact
- All tools set to form ad coolant specification. Many can be converted to form b style
- Maximum 20,000 rpm
| Model | 3856578 |
|---|---|
| Brand Name | WIDIA |
| Unit Count | 1.0 Count |
| Part Number | 3856578 |
| Manufacturer | WIDIA Products Group |
